[TR] How to tell the size of bolt or setscrew from the part number

[David Friedlander]

Hah! Love it, Keith! I could use a boxful of those
second bolts in the illustration: For mismatched holes.....

Dave

On Thu, Jun 18, 2020 at 3:40 PM Keith Stewart <keithstewart at bell.net> wrote:

> These are some of those bolts that are "special in some way". Where do I
> find their part numbers in case I need to order more?
>
>
>
> Keith Stewart
>
> keithstewart at bell.net
>
>
>
>
>
>
>
> -----Original Message-----
> From: Chris Kantarjiev <cak at dimebank.com>
> Sent: June 17, 2020 4:49 PM
>
>
>
> By default, it's grade 5 hardware. Bolts that have part numbers outside
> this system are special in some way - stronger, or have a shoulder, or an
> unusually threaded section. For example, the bolts that connect drive shaft
> flanges are not in this system (and I prefer to use AN hardware for them,
> but that's a different discussion).
>
>
> ** triumphs at autox.team.net **
>
> Donate: http://www.team.net/donate.html
> Archive: http://www.team.net/pipermail/triumphs
> http://www.team.net/archive
>
> Unsubscribe/Manage:
> http://autox.team.net/mailman/options/triumphs/forzion7@gmail.com
>
